KATIA 180

KATIA 180

Mixer Capacity

5m³

Production Capacity

180 m³/Hour

KATIA concrete plants, manufactured using the latest technologies. They are stationary and operate at a true capacity of 180m³ per hour. Each KATIA plant is custom-built according to your requirements and site layout, meaning there are no limits to customisation.

Get a Quote
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
Full Screen
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180
KATIA 180

Why Katia?

It offers easy use with integrated automation software, 24/7 customer service and detailed control options. Its fixed nature provides the advantage of access to high capacities.

Easy maintenace, Features according to needs

The aggregate bunker, belt feets and belt covers are modular, offering easy maintenance with industry-leading platform width. The mixer is customised according to the type of concrete you will produce. Since all chassis wiring is done during production, it offers advantages to the project owner in terms of installation time and cost. Katia, with its wind-resistant solid steel construction, provides high efficiency with accurate weighing and short mixing times.

Advantages
Optional Equipments
KATIA 180
  • KATIA operates at actual capacities ranging from 60 m³ to 180 m³ per hour.
  • The belt feets and belt covers are modular, allowing for easy maintenance.
  • The mixer platform is designed according to requirements, with single or double chute options.
  • All chassis wiring is pre-installed, minimising installation and time costs for the project owner.
  • Vur-Mak Vuruşkan Machinery aims to be your business and solution partner, offering a 24/7 after-sales service support line and a strong mechanical and automation team.
  • Aggregate Bunker Back Steel Ramp: A ramp constructed using backfill soil meets your needs and eliminates the need to deal with concrete demolition work on the ramp wall once the project is complete.
  • Coverings: Optionally, the Aggregate Bunker and Mixer Platform can be enclosed to protect your equipment from external factors such as wind and rain, while also preventing dust from escaping and disturbing the surrounding area.
  • Aggregate Bunker Mesh: The mesh system installed on top of the aggregate bunker prevents large stones from entering your bunker, thus preventing damage to your hoppers.
  • Moisture Probe: By measuring the moisture content of your wet sand and aggregates, it instantly reduces the amount of water in the recipe, maintaining the slump value of the concrete to be poured.
